Corrugated Metal Panels

Corrugated Metal Panels

Corrugated Metal .com carries corrugated metal panels for roofing, flooring, and siding. These corrugated panels are made of rippled metal sheets, one of the most commonly used panels in the industry. Corrugated sheet metal is a tough material, light weight, weather resistant, and practical for many different uses. We specialize in manufacturing top quality corrugated materials for metal roofing, metal siding, corrugated metal decking, and corrugated metal flooring for almost any application.

As an industry leader in providing the best corrugated metal panels, we are able to ensure customer satisfaction by producing metal panels in virtually any material and gauge size. With many different finishes available, we are sure to have something just for your liking.

Corrugated Metal Sheet Sizes

1-1/4″ x 1/4″ Corrugated Panel

Corrugated Metals

The 1-1/4″ corrugated panels primarily come in a galvanized finish, and in lighter gauges. (26-28-29 gauge). This panel has the slightest of the profiles and is used in both decorative & and industrial applications. We can only make this panel profile in almost any material. Please inquire about other finishes such as aluminum & stainless steel. The standard galvanized sheet would come in a standard 26″ wide sheet, with lengths of 8′, 10′, & 12′ long.

2-1/2″ x 1/2″ Corrugated

corrugated panel
corrugated panels

The 2-1/2” x ½” corrugated sheet metal is probably the most common corrugated panel on the market today, and has been used as the standard“ corrugated” for many years now. The 2-1/2” corrugated is typically used for the “pole-barn” and almost simple corrugated structure. The 2-1/2” dimension denotes the distance from the peak of one ‘bump to the peak of the next, and has an overall height of ½”.We typically stock and sell this in the (G-90) galvanized finish as our standard stocking item, but can provide this is any material you require, such as a plain steel, fiberglass, aluminum (smooth & stucco embossed) as well a painted finish and stainless steel, in both the (T-304) & (T316) materials. Our stocking sheets are all galvanized ::

18 – 20 – 22 – 24 – 26 –GAUGES
Galvanized

(41-1/4”Wide in S.S. / Alum. 42”W / Fiberglass 45”W)
(Custom Width & Lengths Available Upon Request)

Other finishes will have varying widths, so please inquire as to which width is the standard for each material type. We also have started offering the 2-1/2” x ½” in a corrugated & perforated panel which is very unique, which we can do almost any hole pattern with. The 2-1/2” x ½” corrugated panel profile is certainly the most common and most versatile panel on them market today and can be used in any application you may need. Please call Corrugated Metal (215-860-3600) with any size inquiry, 1-2 sheets or 1,000 to 2,000 sheets and we can ship directly from our stock sheets. Also, inquire about whatever finish or material you may need and our sales staff will more then happy to customize your quote and material to fit your needs.

(2.67″ x 7/8″) Corrugated :

corrugated panels

The 2.67′ x 7/8″ corrugated profile offers a deep groove for a more pronounced corrugated style. This deeper groove offers a stronger overall panel in any gauge thickness, and allow for a larger span. The 7/8″ corrugated is offer in both the galvalume and aluminum materials in standard lengths of 8′,10′, & 12′ long. The typical material thickness offered are either 18-20-22-or-24 gauge. The corrugated with this 2.67″ spacing is very widely used in many roofing applications with it’s deep grooving allows more run off of water, and gives an overall S-Style that has the look many people are after. We can offer this panel in stainless steel, but we would typically stock in either a plain galvalume material or the aluminum mill finish, with the smooth or stucco-embossed finish. We also spec. this panel with a large number of our perforated & panel requests. We can also quote this material in a painted finish as well. Please call Corrugated Metal with your inquiry and our knowledgeable staff will more then happy to help you with your order, or material quotation.

Corrugated Metal Panels

Corrugated Metal Panels

2-6/7″x3/4″ Corrugated

The 2.67′ x 3/4″ corrugated profile offers a deep groove for a more pronounced corrugated style. This deeper groove offers a stronger overall panel in any gauge thickness, and allow for a larger span. The 3/4″ corrugated is offer in both the galvalume and aluminum materials in standard lengths of 8′,10′, & 12′ long. The typical material thickness offered are either 18-20-22-or-24 gauge. The corrugated with this 2.67″ spacing is very widely used in many roofing applications with it’s deep grooving allows more run off of water, and gives an overall S-Style that has the look many people are after. We can offer this panel in stainless steel, but we would typically stock this in either a plain galvalume material or the aluminum mill finish, with the smooth or stucco-embossed finish. We also spec. this panel with a large number of our perforated & corrugated panel requests. We can also quote this material in a painted finish as well. Please call Corrugated Metal with your inquiry and our knowledgeable staff will more then happy to help you with your order, or material quotation.

MetalOverall WidthsFinishNet CoverageEdgesAvailability
SidingRoofing
Steel & Aluminum31″0SE/MF29 1/3″29 1/3″2 DownStandard
41 3/4″SE/MF40″37 1/3″1 U/DStandard
Corrugated

4.2″ Corrugated

Corrugated Panels

(4.2 panel shown, top to bottom, Galvanized, Bronze-Painted, Aluminum (stucco-embossed) and Kynar painted Beige)

Corrugated Metal Panels

The 4.2 corrugated panel is a high profile, wavy style panel that is used and can be used in almost any roofing, siding, or decorative application. The (4.2) panel groove is similar to the standard 2-1/2″ corrugated and based on the same premise but with bigger more pronounced look. Originally this profile was made in a concrete version and used as an asbestos replacement panel, it is now used in the industry for many others applications where a corrugated look is wanted. The 4.2-Inches denote the distance from one peak to the next peak and has an overall height of 1-1/16″ if were laying flat on the ground, this is deepest “wavy” style of corrugated available anywhere.

The 4.2 Profile is the preferred choice in many applications where a traditional “corrugated” will work but not look as good, or have the strength of this panel. Not many companies in the country even carry the 4.2 wavy style of corrugated, so look no further since, we also stock this and can make it practically in any material our customers can imagine. Below, are stock sizes, but almost anything can be done in a plain-steel or the standard galvanized. We can also, offer this in a painted version, or stainless steel (both T304 & T316, and in 2-B & #4 finishes), and in aluminum with a mill (smooth) finish, or the Stucco-Embossed (pebble finish). Now offering the 4.2 panel in lengths up to 40′ long. We are also the first offer this in a perforated and corrugated panel which is one the top choices by architects and designers. Please call Corrugated Metal and explore all the possibilities when using the (4.2) Corrugated Roofing/ Siding panel.

STOCK SIZES – Galvanized

18-Gauge / 20-Gauge / 22-Gauge / 24-Gauge

All 42″ Wide – 8’Long / 10’Long / 12’Long (max.)

Stock sizes - galvanized
